ASUS Pro WS TRX50-SAGE WiFi AMD TR5 DDR5 E-ATX Workstation Motherboard

Name: ASUS Pro WS TRX50-SAGE WiFi AMD TR5 DDR5 E-ATX Workstation Motherboard
Brand: ASUS
SKU: ASUS-PRO-WS-TRX50-SAGE-WIFI
Price: 80846 INR
Availability: OutOfStock

The ASUS Pro WS TRX50-SAGE WiFi is an E-ATX workstation motherboard on the AMD TRX50 chipset for AMD Ryzen Threadripper 7000-series processors on the TR5 (sTR5) socket. A robust 20 power-stage VRM with ProCool II connectors supports the high sustained TDP demands of multi-core Threadripper CPUs in professional compute environments. Five PCIe 5.0 x16 slots enable full multi-GPU configurations, while four M.2 slots, quad-channel DDR5 ECC memory, dual Ethernet (10GbE + 2.5GbE), Wi-Fi 7, and dual USB4 40Gbps rear ports round out an enterprise-class connectivity suite. Designed for AI inference, 3D rendering, and scientific compute workloads. 3-year manufacturer warranty.

₹80,846

₹1,00,000

Save 19%

Out of Stock

Ask on WhatsApp

Secure Payments

Authentic24-48h ShipPune WorkshopWarranty Claim

Details

Features

20 Power-Stage VRM — Dual ProCool II power connectors with high-current stages sustain the peak TDP of AMD Ryzen Threadripper 7000 processors across extended rendering and AI inference sessions.
Five PCIe 5.0 x16 Slots — Supports up to four-way multi-GPU configurations using discrete x16 electrical PCIe 5.0 slots, enabling maximum compute density for deep-learning and GPU rendering workloads.
Quad-Channel DDR5 ECC Memory — Four DDR5 DIMM slots with ECC support and overclocking profiles deliver up to 256GB of registered memory bandwidth for memory-intensive simulation and data-science tasks.
Dual Ethernet (10GbE + 2.5GbE) — Marvell AQtion 10 Gigabit and Intel 2.5G LAN ports support high-speed NAS, storage area networks, and dedicated management network configurations.
Four PCIe 5.0 M.2 Slots — Four M.2 slots running at PCIe 5.0 speeds provide fast local storage for large datasets, project scratch drives, and OS volumes without using PCIe expansion slots.
Dual USB4 40Gbps Rear Ports — Two USB4 ports deliver Thunderbolt-compatible 40Gbps bandwidth for external GPU enclosures, capture cards, and ultra-fast storage arrays.
Wi-Fi 7 Wireless — Wi-Fi 7 (BE) with Bluetooth enables flexible network deployment for workstations installed away from wired infrastructure in studio or lab environments.

In the Box

ASUS Pro WS TRX50-SAGE WiFi Motherboard
SATA cables
Wi-Fi antenna
M.2 rubber package
User manual / quick installation guide

Technical Specification

Spec	Value
ASIN	B0CMZHDQPD
Model	PRO WS TRX50-SAGE WIFI
CPU Socket	TR5 (sTR5)
Compatible CPUs	AMD Ryzen Threadripper 7000 Series
Chipset	AMD TRX50
Form Factor	E-ATX
Memory Type	DDR5 ECC
Memory Slots	4 × DIMM (Quad-channel)
Memory Max	256GB
PCIe Slots	5 × PCIe 5.0 x16
M.2 Slots	4 × PCIe 5.0 M.2
SATA Ports	4
Wireless	Wi-Fi 7 (BE)
Ethernet	Marvell 10GbE + Intel 2.5GbE
USB (Rear)	2 × USB4 40Gbps, USB 3.2 Gen 2
VRM	20-stage ProCool II
Item Weight	2.5 kg
Country of Origin	China
Importer	Rashi Peripherals
Warranty	3 Years
