01 / 06ASUS Pro WS TRX50-SAGE WiFi AMD TR5 DDR5 E-ATX Workstation Motherboard
The ASUS Pro WS TRX50-SAGE WiFi is an E-ATX workstation motherboard on the AMD TRX50 chipset for AMD Ryzen Threadripper 7000-series processors on the TR5 (sTR5) socket. A robust 20 power-stage VRM with ProCool II connectors supports the high sustained TDP demands of multi-core Threadripper CPUs in professional compute environments. Five PCIe 5.0 x16 slots enable full multi-GPU configurations, while four M.2 slots, quad-channel DDR5 ECC memory, dual Ethernet (10GbE + 2.5GbE), Wi-Fi 7, and dual USB4 40Gbps rear ports round out an enterprise-class connectivity suite. Designed for AI inference, 3D rendering, and scientific compute workloads. 3-year manufacturer warranty.
Features
- 20 Power-Stage VRM — Dual ProCool II power connectors with high-current stages sustain the peak TDP of AMD Ryzen Threadripper 7000 processors across extended rendering and AI inference sessions.
- Five PCIe 5.0 x16 Slots — Supports up to four-way multi-GPU configurations using discrete x16 electrical PCIe 5.0 slots, enabling maximum compute density for deep-learning and GPU rendering workloads.
- Quad-Channel DDR5 ECC Memory — Four DDR5 DIMM slots with ECC support and overclocking profiles deliver up to 256GB of registered memory bandwidth for memory-intensive simulation and data-science tasks.
- Dual Ethernet (10GbE + 2.5GbE) — Marvell AQtion 10 Gigabit and Intel 2.5G LAN ports support high-speed NAS, storage area networks, and dedicated management network configurations.
- Four PCIe 5.0 M.2 Slots — Four M.2 slots running at PCIe 5.0 speeds provide fast local storage for large datasets, project scratch drives, and OS volumes without using PCIe expansion slots.
- Dual USB4 40Gbps Rear Ports — Two USB4 ports deliver Thunderbolt-compatible 40Gbps bandwidth for external GPU enclosures, capture cards, and ultra-fast storage arrays.
- Wi-Fi 7 Wireless — Wi-Fi 7 (BE) with Bluetooth enables flexible network deployment for workstations installed away from wired infrastructure in studio or lab environments.
In the Box
- ASUS Pro WS TRX50-SAGE WiFi Motherboard
- SATA cables
- Wi-Fi antenna
- M.2 rubber package
- User manual / quick installation guide
Technical Specification
| Spec | Value |
|---|---|
| ASIN | B0CMZHDQPD |
| Model | PRO WS TRX50-SAGE WIFI |
| CPU Socket | TR5 (sTR5) |
| Compatible CPUs | AMD Ryzen Threadripper 7000 Series |
| Chipset | AMD TRX50 |
| Form Factor | E-ATX |
| Memory Type | DDR5 ECC |
| Memory Slots | 4 × DIMM (Quad-channel) |
| Memory Max | 256GB |
| PCIe Slots | 5 × PCIe 5.0 x16 |
| M.2 Slots | 4 × PCIe 5.0 M.2 |
| SATA Ports | 4 |
| Wireless | Wi-Fi 7 (BE) |
| Ethernet | Marvell 10GbE + Intel 2.5GbE |
| USB (Rear) | 2 × USB4 40Gbps, USB 3.2 Gen 2 |
| VRM | 20-stage ProCool II |
| Item Weight | 2.5 kg |
| Country of Origin | China |
| Importer | Rashi Peripherals |
| Warranty | 3 Years |
